| Model Number | Description | Downloads | Part Number | Clear Opening |
|---|---|---|---|---|
| BMHC15X23BS | Manhole – 15×23 Weld Bolt, Flush | Cutout & CAD Files: PDFDXF  |
02590-105A | |
| BMHC15X23F | Manhole 15X23 20-Bolt, Flush | Cutout & CAD Files: PDFDXF |
08866-101F | |
| BMHC15X23H | Manhole -15X23 20-Bolt w/ 3″ NPT Flush | Cutout & CAD Files: PDFDXF |
08866-101H | |
| BMHC15X23S | Manhole -15X23 20-Bolt | Cutout & CAD Files: PDFDXF |
08866-101S | 15 x 23 |
| BMHC15X23Z | Manhole -15X23 20-Bolt w/ 3″ NPT Raised | Cutout & CAD Files: PDFDXF |
08866-101Z | |
| UMC-502 | Raised 18×24 24-Bolt Manhole w/ 2.5″ Coaming | Cutout & CAD Files: PDFDXF |
02580-101A | |
| UMC-503 | Manhole – 15×23 20-Bolt, Flush | Cutout & CAD Files: PDFDXF |
02590-101A | |
| UMC-505 | Manhole 15×23 26-Bolt, Flush | 02610-101A | ||
| UMC-501 | Raised 15×23 20-Bolt Manhole w/ 2.5″ Coaming | Cutout & CAD Files: PDFDXF |
02570-101A | |
| UMC-154-14 | Raised 14″ Round Clean-Out Hatch | 08451-101A | ||
| UMC-154-14-SS | Raised 14″ Round Clean-Out Hatch SS | 08451-102B | ||
| UMC-154-18 | Raised 18′” Round Clean-Out Hatch | 08450-101A | ||
| UMC-154-18-SS | Raised 18″ Round Clean-Out Hatch SS | 08450-102B | ||
| 08866-110A | Clean-Out Hatch – Round 10″ | 08866-110A |
Disclaimer of Liability: PDF Cutout drawings, Autocad® Cutout drawings and SSI drawings (the “Drawings”) are provided for convenience only without warranty of any kind. Baier makes no representation regarding the completeness, accuracy, reliability, timeliness or compatibility of the Drawings or that the Drawings will be error-free. Baier assumes no responsibility or liability for anyone's use of the Drawings, and Baier shall not be liable for any loss or damage of whatever nature (direct, indirect, consequential, or other) whether arising in contract, tort or otherwise, which may arise as a result of anyone’s use of the Drawings.
We are working to complete our library of available drawings for our customers. If the drawing you want does not appear, is too large or otherwise unsuitable for your use, please contact us and we will investigate alternatives for you.
This website is independent of Autodesk®, Inc., and is not authorized by, endorsed by, sponsored by, affiliated with, or otherwise approved by Autodesk®, Inc.
SSI files are digital models of Baier Equipment formatted for SSI™s popular ShipConstructor CAD/CAM software (XML files are compatible with ShipConstructor version 2016 R2 and greater). For a complete list of all available Baier Products formatted for SSI ShipConstructor go to our Download Library. For more information about SSI ShipConstructor Contact your local SSI Reseller to discuss the most cost-effective solution for you. Learn more.
